Oberdorfer Pump # 209M Macerator Pump Head
Oberdorfer Pump # 209M Macerator Pump Head
Oberdorfer 209M Macerator Pump Head Only, Bronze, No Motor.
Regular price
$ 468.66 USD
Regular price
Sale price
$ 468.66 USD
Unit price
/
per
Shipping calculated at checkout.
We currently have 2 in stock, and can ship
tomorrow before 4 PM EST.
Couldn't load pickup availability
FEATURES :
Pump Body: Bronze
Ports: Inlet: 2" Slip-on Hose and 1 1/2" Pipe Thread Outlet: 3/4" Garden Hose and 3/8" Pipe Thread
Flow: 9.0 GPM Max
Pressure: 12 PSI Max
Impeller: Flexible Rubber Impeller Neoprene standard, Buna Optional.
Shaft Seal: Lip Seal
Shaft: Stainless Steel Motor Shaft
Motor / Drive: 12, 24 or 32VDC high torque, 18 amps. Intermittent duty cycle. Do not run pump dry.
APPLICATIONS:
BRONZE CLOSE COUPLED RUBBER IMPELLER PUMP, SEWAGE - MACERATOR Used in: Utility Trailers, Boats, Railroads, Buses, Motor Homes, Emergency, Campers, Mobil Homes, Cottages, Camp Sites, Aircraft, Marine Transporation, Recreational Vehicles, Land & Water Cruisers, Commercial & Pleasurecraft. Will handle sewage, waste, toilet paper, cigarettes, cigars and all maceratable solids of approximately 1 inch size. Self priming up to 4 ft. Up to 20 ft. uphill discharge or up to 50 ft. away. (Use large diameter garden hose - 3/4” - for best results.) A 30 gallon holding tank can be emptied in less than 4 minutes. Motor Shaft Slinger Protects Motor Bearings. Rubber Motor Grommets for Noise Isolation. Macerator Wheel and Impeller Easily Replaced. Removable Base.
View full details
Pump Body: Bronze
Ports: Inlet: 2" Slip-on Hose and 1 1/2" Pipe Thread Outlet: 3/4" Garden Hose and 3/8" Pipe Thread
Flow: 9.0 GPM Max
Pressure: 12 PSI Max
Impeller: Flexible Rubber Impeller Neoprene standard, Buna Optional.
Shaft Seal: Lip Seal
Shaft: Stainless Steel Motor Shaft
Motor / Drive: 12, 24 or 32VDC high torque, 18 amps. Intermittent duty cycle. Do not run pump dry.
APPLICATIONS:
BRONZE CLOSE COUPLED RUBBER IMPELLER PUMP, SEWAGE - MACERATOR Used in: Utility Trailers, Boats, Railroads, Buses, Motor Homes, Emergency, Campers, Mobil Homes, Cottages, Camp Sites, Aircraft, Marine Transporation, Recreational Vehicles, Land & Water Cruisers, Commercial & Pleasurecraft. Will handle sewage, waste, toilet paper, cigarettes, cigars and all maceratable solids of approximately 1 inch size. Self priming up to 4 ft. Up to 20 ft. uphill discharge or up to 50 ft. away. (Use large diameter garden hose - 3/4” - for best results.) A 30 gallon holding tank can be emptied in less than 4 minutes. Motor Shaft Slinger Protects Motor Bearings. Rubber Motor Grommets for Noise Isolation. Macerator Wheel and Impeller Easily Replaced. Removable Base.
