Jabsco Pump # 22880-2003 Bronze Pump Head
Jabsco Pump # 22880-2003 Bronze Pump Head
Jabsco 22880-2003 Bronze Pump Head Only, Flanged Ports, Port Fittings Not Included.
Regular price
$ 1,451.57 USD
Regular price
Sale price
$ 1,451.57 USD
Unit price
/
per
Shipping calculated at checkout.
Out of Stock.
Couldn't load pickup availability
FEATURES :
Pump Body: Bronze Head Kit with Motor Adaptor
Port Size: Flanged
Flow: up to 200 litres/minute @ 1500 RPM
Impeller: Neoprene or Nitrile
Shaft Seal: Carbon/Ceramic mechanical seal, Nitrile.
Shaft: Stainless steel shaft extension
Motor Bracket: Epoxy-coated aluminium, suitable for B3/B14 D100 frame motor to IEC 71 standard
APPLICATIONS:
Self primes from dry up to 3.0 metres. Handles hard or soft solids. Non pulsating flow. Gentle pump action does not damage shear-sensitive products. Easy to service and maintain. INDUSTRIAL: From water to the most difficult, e.g. transferring foaming solutions with entrained air or solids, such as soap, circulating abrasive and non abrasive slurries. Transferring inks, dyes, starches etc. CHEMICAL: Circulating and transferring various chemicals such as ammonia, barium, copper sulphate, glycerine, nickel chloride, silver nitrate; various acids such as boric, carbonic, citric and photo processing solutions, widely used for polyelectrolyte.
View full details
Pump Body: Bronze Head Kit with Motor Adaptor
Port Size: Flanged
Flow: up to 200 litres/minute @ 1500 RPM
Impeller: Neoprene or Nitrile
Shaft Seal: Carbon/Ceramic mechanical seal, Nitrile.
Shaft: Stainless steel shaft extension
Motor Bracket: Epoxy-coated aluminium, suitable for B3/B14 D100 frame motor to IEC 71 standard
APPLICATIONS:
Self primes from dry up to 3.0 metres. Handles hard or soft solids. Non pulsating flow. Gentle pump action does not damage shear-sensitive products. Easy to service and maintain. INDUSTRIAL: From water to the most difficult, e.g. transferring foaming solutions with entrained air or solids, such as soap, circulating abrasive and non abrasive slurries. Transferring inks, dyes, starches etc. CHEMICAL: Circulating and transferring various chemicals such as ammonia, barium, copper sulphate, glycerine, nickel chloride, silver nitrate; various acids such as boric, carbonic, citric and photo processing solutions, widely used for polyelectrolyte.
